•Gold plated beryllium copper seizure has ideal electrical and mechanical characteristics, with exceptional spring back and center conductor retention
•100% conformance to SCTE standards for center conductor retention without any assistance from plastic insulators that relax over time
•High quality zinc alloy body
•Nickel plating for excellent corrosion resistance
•Precision machined SCTE conforming ports for superior F-connector performance

•Bandwidth: 5 to 3,000 MHz
•Impedance: 75 Ohms
•Return Loss: 30 dB @ 5 to 1,000 MHz, ≤ 0.3 @ 600 to 3,000 MHz
•Ground Wire Gauge: Accepts up to #6 AWG ground wire
•Operating Temperature: -40°C to +60°C (-40°F to +140°F)

•1 x Coaxial Cable Grounding Block
•2 x Mounting Screws
•1-Year Limited Warranty
