• LTE-certified Digi CORE plug-in modem
• Advanced routing capabilities to help you match your use case
• Scalable cellular technology allows you to match speeds to applications and future proof your network
• Optimized connectivity to any Ethernet device
• Multiple mounting options and accessories
• Serial port for remote, out-of-band managementSerial port for remote, out-of-band management
• Zero-touch provisioning and cloud management
• Includes the Digi 360 solution with warranty, customer care and Digi Remote Manager cloud management, enabling easy setup, mass configuration and management
• Value-added services include Digi Containers to enable powerful, cost-efficient applications and Digi WAN Bonding for 5G/LTE WAN aggregation with immediate failover

• Cellular connectivity: LTE-Advanced Cat 7 LTE-A Cat 7 (US): B2, B4, B5, B7, B12, B13, B25, B26, B41, B42, B43, B48, B66, B71 WCDMA: B2, B5 Transfer rate (max): 300 Mbps, 150 Mbps up
• Base hardware: (2) RJ-45 Ethernet, (1) RJ-45 RS-232
• Remote management: Digi Remote Manager®
• Operating temperature: 0 °C to 40 °C (32 °F to 104 °F)
• Remote Management: Digi Remote Manager; SNMP v3 (user installed/managed), encrypted SMS
• Local Management: WebUI (HTTPS/HTTPS); CLI (SSH, serial port)
• Protocols: RIP, RIPng, OSPFv2, OSPFv3, BGP, Babel, IS-IS

• Digi EX15: 2-port GigE; RJ-45, RS-232; LTE-A / HSPA+ Cat 7
• Power: 18 V PSU power supply with barrel jack connector (450061)
• PoE injector: Cable assembly passive POE power injector, white 2.1 mm barrel connector (500157)
• Antenna: Cellular antenna, quantity 2 (170017)
• *** Warranty may vary on model ***

5.6-in x 5-in x 1.2-in

0.44 lbs

Datasheet
