•Platinum HD antennas deliver powerful VHF performance and offer additional 1 dB to 2 dB higher gain on VHF and UHF, important for weak signal areas.
•Great for the those in a low signal areas, trying to overcome loss from trees, and terrain or those who simply want the best
•High quality construction offers extra strength with double boom braces, high-impact ABS girder design and supports
•Outstanding UHF reception achieved by precise director spacing and highly efficient corner reflectors
•No transformer required, this antenna uses a unique PC board with a direct 75 Ohm connection
•Includes hardware for mounting to a mast; antenna has a 75 ohm coax connection
•FREE TV - This antenna pays for itself in the second month based on $100 cable bill
•Directional performance offers high gain reception while blocking out interference
•Cut the cord with confidence - this antenna gets both VHF and UHF transmissions
•69 Active Elements, 34 VHF elements, and 35 UHF elements
•Best possible reception on VHF and UHF

•Wave band: VHF: 100+ miles, UHF: 60+ miles
•Size: 33"(H) x 110"(W), Boom length: 168 1/4"
•Gain: Average: 2-6 ch: 5.9dB, 7-13 ch: 11.5dB, 14-69 ch: 13.3dB and Avg front to back: 2-6 ch: 18dB, 7-13 ch: 18.8dB, 14-69 ch: 19.3dB
•Avg beamwidth: 2-6 ch: 65°, 7-13 ch: 37°, 14-69 ch: 38°
•Turning radius: 101"
•69 active elements, 34 VHF elements, and 35 UHF elements

•Front Assembly
•Rear Assembly
•Boom Brace
•Corner Reflector Assembly (2)
•Cartridge Housing
•Boot

10 lbs
