SureCall Ultra Low-Loss Plenum Rated SC-400 Coax Cable - 500'

Features

•UL-rated for plenum ceilings (UL E473791)
•Ultra low-loss SC-400 cable
•N-Male connectors on both ends
•50 Ohm
•Weatherproof, heat shrunk and tested
•RoHS compliant and UL approved

Technical Specifications

•Inner Conductor: Copper clad aluminum wire (2.74 mm)
•Dielectric: Foam PE (7.24 mm)
•Outer Conductor: (a) Aluminum foil + (b)Tinned copper braid (8.13 mm)
•Jacket: FRPE (8.93 mm)
•Bend Radius (Installation): 45 mm
•Bend Radius (Repeated): 65 mm
•Velocity: 85%
•Dielectric Constant: 1.73
•Impedance: 50 ohm
•Capacitance: 78 pF/m
•Shielding Effectiveness: >90 dB
•Operating Temperature: -40°C ~+60°C

Box Contents

•1 x 500-ft Ultra Low-Loss Plenum SC-400 Coax Cable

Weights & Dimensions

Datasheets

SureCall Ultra Low-Loss Plenum Rated SC-400 Coax Cable - 500'

Vendor: SureCall

SKU: CASC-PL-500-WHITE

Vendor SKU: SC-PL-500-White

Shipping calculated at checkout.

Special Order Item

Oversized Item, Special Shipping Required

Manufacturer's Warranty: 3-Year

Add-ons

SureCall 400 Coaxial Series Cable Prep Tool

SureCall Coax Cable Crimping Tool

UL-listed Plenum SC-400 fire-rated coaxial cable with N-Male connectors can be used inside plenum ceilings to connect SureCall cell phone signal boosters with antennas. Almost all large buildings utilize the ceiling for returning air to the AC unit, thereby making it a plenum ceiling which means all cables running through the ceiling needs to be plenum rated cable.

Length: 152.4-meters (500-ft)

152.4-meters (500-ft)

Colour: White

Special order items do not qualify for same day shipping.
No returns of exchanges on Special Order Items.
Pricing is subject to change.

Oversized Items will require special shipping. We will contact you to finalize shipment.
Read our Special Order Policy

Features

•UL-rated for plenum ceilings (UL E473791)
•Ultra low-loss SC-400 cable
•N-Male connectors on both ends
•50 Ohm
•Weatherproof, heat shrunk and tested
•RoHS compliant and UL approved
