•Ideal Wi-Fi AP for voice-over-Wi-Fi deployments and offers a seamless connection with Grandstream’s Wi-Fi capable IP phones.
•Supported by GWN.Cloud and GWN Manager, Grandstream’s free cloud and on-premise Wi-Fi management platform
•5.38 Gbps wireless throughput and 3.5 Gigabit wireline ports
•5GHz 4×4:4 MU-MIMO with DL/UL OFDMA technology
•Up to 175-meter coverage range
•Supports 256 concurrent Wi-Fi client devices
•Advanced QoS to ensure real-time performance of low-latency applications
•Anti-hacking secure boot and critical data/control lockdown via digital signatures, unique security certificate/random default password per device
•Self power adaptation upon auto detection of PoE or PoE+
•Embedded controller manages up to 50 local GWN APs; GWN.Cloud offers unlimited AP management, & GWN Manager offers on-premise software AP management

•Wi-Fi Standards: IEEE 802.11 a/b/g/n/ac(Wave-2)/ax
•Antennas: 2.4GHz - gain 3.65dBi; 5GHz - gain 5.26dBi (6 x single frequency internal antennas)
•Frequency Bands: 2.4 GHz Radio @ 2412 - 2484 MHz; 5 GHz Radio @ 5180 - 5825 MHz
•Channel Bandwidth: 2.4G - 20 and 40MHz; 5G - 20, 40, 80MHz
•Wi-Fi and System Security: WEP, WPA/WPA2-PSK, WPA/WPA2 Enterprise (TKIP/AES); WPA3, anti-hacking secure boot and critical data/control lockdown via digital signatures, unique security certificate and random default password per device
•MIMO: 2×2:2 2.4GHz(MIMO); 4×4:4 5GHz(MU-MIMO)
•Coverage Range: Up to 175 meters
•Maximum TX Power: 2.4G - 25dBm; 5G - 27dBm
•Concurrent Clients: Up to 256
•Network Interfaces: 1 x autosensing 10/100/1000 Base-T Ethernet Port; 1 x autosensing 10/100/1000/2500 Base-T Ethernet Port
•Network Protocols: IPv4, IPv6, 802.1Q, 802.1p, 802.1x, 802.11e/WMM
•Operating Environment: -10°C to 45°C (5% to 95% non-condensing)

•1 x GWN7662 indoor Wi-Fi 6 Wireless AP
•1 x Indoor Wall Mount Kit
•1 x Indoor Ceiling Mount Kit
•Quick Installation Guide
