•5 x Gigabit RJ45 ports, 8 x port PoE+ output
•PoE - 802.3 af/at compliant, Up to 30W on each port
•Green technology reduces power consumption
•LED Indicators for both Link/Activity (per port) and Power (per device)
•Auto MDI/MDIX crossover for all ports
•Broadcast/Multicast/Unicast Storm Control (fixed to 100Mbps) to monitor traffic levels
•Supports long cable connection
•QoS - Supports Default Strict Priority when present
•Metal enclosure

•Ethernet Ports: 8 × 10/100/1000Mbps RJ45 Ports (AUTO Negotiation, AUTO MDI/MDIX)
•PoE Ports: 1-8 (802.3 af/at compliant)
•PoE Power: Up to 30 W on Each Port, Total 145 W Power Budget
•Network Protocols: IEEE 802.3i, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3x
•Network Media: 1000Base-T/100Base-TX/10Base-T, Half/Full-Duplex
•Mac Address Table: 8K
•Switching Capacity: 16Gbps
•Jumbo Frame: 9KB
•Power Adapter: Internal 100-240 V AC, 50/60Hz, 150 W
•Max Power Consumption by Base System: 6.7W @220 V/50 Hz (excluding PoE output power)
•Operating Environment: Temperature 0°C to 40°C (32°F to 104°F); Humidity 10% to 90% Non-condensing
•Compliance: FCC, CE, RCM, IC, UKCA

•1 x Switch
•1 x AC Cable (1.2-meter)
•2 x Rack-Mounting Standard Brackets
•4 x Rubber feet
•Quick Installation Guide

Datasheet
