•Unique asymmetrical beam cross-section in bore sight is elliptical (wide in azimuth and narrow in the elevation plane)
•The antenna provides unique asymmetrical beam shape while maintaining excellent noise rejection
•The antenna has naturally suppressed side lobes because of their optimized design (they focus energy into a single main beam)
•Absence of side lobes enables excellent noise immunity of a network when using the antenna
•The radiation pattern of the Antenna is stable over the whole band width of operation
•Asymmetrical Horn CC Antennas have balanced Horizontal and Vertical beam patterns
•The antenna has higher gain compared to Symmetrical Horn Antennas with the same azimuth beam width
•Antennas provide extra degrees of the elevation beam width, shrinking the null zone while preserving the increased gain for long-range performance
•The antenna enables extraordinary network scalability
•The antenna features N-female connectors, used with a wide range of radios, such as Mimosa A5c, Cambium Networks PMP 450, LigoWave, and many others
•The antenna has solid aluminium body, built to last and resist any weather conditions

•Antenna Type: Horn
•Radio Connection: 2x N Female Bulkhead Connector
•Environmental: IP55
•Frequency Range: 5180 - 6000 MHz
•Gain: 20.5 dBi
•Azimuth Beam Width -3 dB: H 21° / V 21°; Azimuth Beam Width -6 dB: H 30° / V 30°
•Elevation Beam Width -3 dB: H 15° / V 15°; Elevation Beam Width -6 dB: H 20° / V 20°
•Beam Efficiency: 95%
•VSWR Max 5180-6000 MHz: 1.8
•Temperature: -35°C to +55°C (-31°F to +131°F)
•Wind Survival: 160 km/hour
•Wind Loading: 67 N at 160 km/hour

•1 x Asymmetrical Horn CC Antenna
•1 x Bracket Base
•1 x Bracket Arm
•1 x Bracket
•6 x M6 x 20mm Screw
•2 x M8 x 75mm Screw
•1 x Handle
•User Manual
