•Programmable Transmit Power: The radio's transmit power level can be programmed up to +29 dBm
•Programmable Duty Cycle (GPS synchronized frames): The AF-5XHD allows configuration of asymmetric TX and RX duty cycles. TX ratios include 25%, 33%, 50%, 66.7%, and 75%.
•Configurable GPS Synchronization: The AF-5XHD offers configurable support for 2, 2.5, 4, and 5 ms frames. Timing is compatible with all other synchronous systems
•Adaptive Modulation up to 1024QAM Adaptive modulation rates of up to 1024QAM (4096QAM with targeted upgrade) are supported.
•Dual Redundant Gigabit Ethernet Ports with PoE The AF-5XHD has two Gigabit Ethernet ports that can be used to provide redundant PoE power.
•Bluetooth Wireless Configuration: Use the built-in Bluetooth interface for wireless configuration

•Frequency Range: 4.8 GHz - 6.2 GHz (Dependent on Regulatory Region)
•Max. Conducted TX Power: 29 dBm (Dependent on Regulatory Region)
•Weatherproofing: IP67
•Operating Temperature: -40°C to 55°C (-40°F to 131°F)
•Maximum Throughput: 1.34 Gbps
•Maximum Range: 100 km
•Packets per Second: 2+ Million
•Latency: 1.5 ms - 3.5 ms
•Encryption: AES-256

•1 x Radio
•1 x PoE
•1 x GPS Holder
•1 x Mount Spacer
•1 x GPS Antenne
•1 x Power Cord
