•Carrier-class construction and 2 x 2 dual-polarity performance
•Provides sector-wide coverage and utilizes airMAX technology
•High resistance to noise interference provides excellent gain and beam performance for high-capacity, multi-point networks
•Robust design for outdoor applications
•Provision of Rocket mount allows for tool-free installation of RocketM BaseStation

•Frequency Range: 902-928 MHz
•Gain: 13.2-13.8dBi
•Polarization: Dual Linear
•Cross-pol Isolation: 30dB min
•Max VSWR: 1.5:1
•Hpol Beamwidth (6dB): 109°
•Vpol Beamwidth (6dB): 120°
•Elevation Beamwidth: 15°
•Electrical Downtilt: N/A
•ETSI Specification: N/A
•Dimensions: 50.8 x 11.4 x 5.3in (1290 x 290 x 134mm)
•Weight: 27.6lbs (12.5kg)

•1 x Antenna
•1 x Antenna Bottom Cover
•2 x U-Brackets
•3 x V-Brackets
•2 x M12x180 Bolts
•2 x M12x130 Bolts
•4 x M8x25 Bolts
•1 x M3x8 Tapping Screw
•8 x  M12 Serrated Flange Nuts
•4 x  M8 Serrated Flange Nuts
•1 x Bushing
•Quick Start Guide
