• 24 x Etherlighting™ and LED combination RJ45 ports that illuminate to indicate port location, speed/link, and native VLAN/network (Pair with UniFi Enterprise Patch Cable for optimal brightness)
• 2 x Etherlighting™ SFP28 ports
• 1.3" Touchscreen display with AR switch management
• Layer 3 switching features
• 4 x Hot-swappable fan modules
• 2 x Hot-swappable 600W power modules

• 2.5 GbE RJ45 Ports: 8 (All PoE+++) (2.5G/1G/100M/10M)
• 10 GbE RJ45 Ports: 16 (All PoE+++) (10G/5G/2.5G/1G/100M/10M)
• 25G SFP28 Ports: 2 (25G/10G/1G)
• Max. PoE Output: Up to PoE+++
• Total PoE Availability: 100-240V AC Shared Mode - 1,050W with (2) 600W modules; 100-240V AC Redundant Mode - 450W with (2) 600W modules
• Switching Capacity: 460 Gbps
• Total Non-Blocking Throughput: 230 Gbps
• Forwarding Rate: 342 Mpps
• Supported VLANs: 1,000
• MAC Address Table Size: 128,000
• ESD Protection: Air ± 30kV, contact ± 30kV
• Operating Environment: Temperature -5°C to 40°C (23°F to 104°F); Humidity 10% to 90% noncondensing

• 1 x Enterprise Campus 24 PoE
• 4 x Hot-swappable fan modules
• 2 x Hot-swappable power modules
• 2 x Power cord
• 1 x DIN Rail Mounting Kit
• Mounting Hardware

20.9 lbs

17.4-in x 1.7-in x 19.5-in
