•Integrates router, PoE switch, and Omada controller altogether
•Dual-Core 1.2 GHz CPU with 1GB DDR3 memory provides stellar performance for up to 12× Gigabit ports
•Equipped with 2 × Gigabit SFP WAN/LAN ports, 1 × Gigabit RJ45 WAN port, and 1 × Gigabit RJ45 WAN/LAN port
•8 × 802.3at/af-compliant PoE+ RJ45 LAN ports yield a total power supply of 110W
•Cloud access and the Omada app offer convenience and easy management
•Cloud access and the Omada app offer convenience and easy management.
•Fanless and compact design for desktop and wall mounting

•Standards and Protocols: IEEE 802.3, IEEE802.3u, IEEE802.3ab, IEEE802.3z, IEEE 802.3x, IEEE 802.1q; TCP/IP, DHCP, ICMP, NAT, PPPoE, NTP, HTTP, HTTPS, DNS, IPSec, PPTP, L2TP, SNMP
•Interface: 2 x Gigabit SFP WAN/LAN ports, 1 x Gigabit WAN port, 1 x Gigabit LAN/WAN port, 8 x Gigabit LAN ports
•Network Media: 10BASE-T - UTP category 3, 4, 5 cable (Max 100 m),EIA/TIA-568 100Ω STP (Max 100 m); 100BASE-TX - UTP category 5, 5e cable (Max 100 m), EIA/TIA-568 100Ω STP (Max 100 m); 1000BASE-T - UTP category 5, 5e, 6 cable (Max 100 m)
•Power Supply: 53.5VDC/2.43A Adapter
•PoE Budget: 8 ports PoE+ output, 110 W PoE Budget
•Flash: 8Mb Nor + 4 GB EMMC
•DRAM: 1 GB DDR3
•Protection: 4 kV Surge Protection
•WAN Connection Type: Static IP, Dynamic IP, PPPoE, PPTP, L2TP
•DHCP: DHCP Server, DHCP Address Reservation, Multi-IP Interfaces, Multi-Net DHCP
•VLAN: 802.1Q VLAN
•Operating Environment: Temperature 0°C to 45°C (32°F to 113°F); Humidity 10% to 90% non-condensing

•1 x ER7212PC
•1 x Power Adapter
•1 x Power Cord
•Quick Installation Guide
