•Real-time reporting
•Spectral analysis
•Advanced RF analytics
•Dedicated Wi-Fi radio for management
•Versatile Mounting: Suitable for indoor and outdoor installations
•Improved Surge Protection: The NanoStation AC utilize the latest ESD Protection to help protect against power surges.
•Efficient Footprint: The radio and antenna are combined into a single body that takes up minimal space.
•Quick Installation: No fasteners are required for pole mounting

•Throughput: Up to 450+ Mbps Real TCP/IP Throughput
•Operating Frequency (MHz): 5150 - 5250, 5725 - 5850
•Management Radio (MHz): 2412 - 2462
•Power Supply: 24V, 0.5A Gigabit PoE Supply
•Max. Power Consumption: 8.5W
•Power Method: Passive PoE (Pairs 4, 5+; 7, 8 Return)
•Gain: 16 dBi
•Networking Interface: 10/100/1000 Mbps Ethernet Port
•Channel Bandwidths: 10/20/30/40/50/60/80 MHz
•Operating Temperature: -40°C to 70°C (-40°F to 158°F)
•Operating Humidity: 5 to 95% Non-condensing

•1 x NanoStation
•1 x Wall Mount Bracket
•2 x Screws
•2 x Screw Anchors
•2 x Zip Ties
•1 x Gigabit PoE Adapter
•1 x Power Cord
•Quick Start Guide
