• Centralized Management: Supports up to 100 Omada access points, 10 Omada gateways, a maximum of 20 Omada switches, and a maximum of 2 certain DeltaStream GPON OLTs
• Free Cloud Access:  Manage and monitor with the Omada app or Web UI from anywhere, anytime
• On-Premises Management:  Locally monitor and manage devices with the ultimate stability and complete privacy
• Hardware Design for Businesses:  Features a powerful chipset, durable metal casing, USB 2.0 port for data backup, and two Gigabit Ethernet ports
• Flexible Deployment:  Powered via 802.3af PoE or Micro USB (DC 5V/Minimum 1A) with a compact desktop or wall mount installation

• Interface: 2 x Gigabit Ethernet Ports; 1 x USB 2.0 Port; 1 x Micro USB Port
• Power Supply: 802.3af PoE; Micro USB (DC 5V/Minimum 1A）
• Centralized Management: 100 Omada access points; 10 Omada gateways; A maximum of 20 Omada switches; A maximum of two select DeltaStream GPON OLTs (The number of supported Omada switches decreases by five for each DeltaStream GPON OLT added)
• Cloud Access: Yes
• L3 Management: Yes
• Multi-site Management: Yes
• Management Features: Automatic Device Discovery, Batch Configuration, Batch Firmware Upgrading, Intelligent Network Monitoring, Abnormal Event Warnings, Unified Configuration, Reboot Schedule, Captive Portal Configuration
• Certifications: CE, FCC, RoHS
• Operating Temperature: -5°C~50°C (23°F~122°F)
• Operating Humidity: 10%~90% non-condensing

• 1 x Omada Hardware Controller OC220
• 1 x RJ45 Ethernet Cable
• Quick Installation Guide

3.9-in x 3.9-in x 1-in 0.68 lbs
