•500Mbps PtMP subscriber unit
•4.9-6.0 GHz frequency range
•Range of up to 40 km / 25 miles
•Committed Information Rate (CIR) & best effort service level
•Automated installation via mobile app
•Interoperable with all RADWIN Base stations
•Supports Jumbo frames
•Operable also as PtP unit
•Highly durable - IP 67

•Architecture: Outdoor Unit with connectors for external antenna (2 x N-Type)
•Data interfaces: 10/100/1000 Mbps RJ45 PoE
•POE and ODU interfaces: Outdoor CAT-5e; Maximum cable length: 75m for 1000BaseT
•Max Capacity: 500 Mbps net aggregate throughput (up to 250 Mbps per direction)
•Range: Up to 40 km / 25 miles (in PtMP mode); Up to 80 km / 50 miles (in PtP mode)
•Default Band: 5.4 GHz
•Regulation: ISED RSS-247
•Dynamic Channel BW Selection: 20/40/80 MHz
•Modulation: OFDM (BPSK/QPSK/16QAM/64QAM/256QAM)
•Antenna Modes: MIMO 2x2 , diversity , adaptive MIMO/diversity
•Power Consumption: <13W (Power provided over ODU-IDU cable)
•Operating Environment: Temperature -35°C to 60°C / -31°F to 140°F; Humidity 100% condensing

•1 x Radio unit
•1 x IP67 Cable gland
•2 x Pole mount bands
•1 x AC PoE adapter
