•Dual carrier base station 4.9-6.0 GHz
•Up to 1.5Gbps per Unit
•Up to 5Gbps per site @ 4 x 40MHz
•Exceptional service reliably and interference mitigation
•Support 128 customers
•WAN Interfaces: Fiber (SFP) and GbE
•Backward compatible with RADWIN Subscriber Unit install base
•Network synchronization via built-in GPS
•Configurable sector width: 90°, 60°, 45°
•Superior Interference immunity with beamforming antenna
•IP67 protection means it is totally protected against dust and against immersion in water up to 1m

•Max Net Aggregate Capacity: 1.5Gbps
•Frequency Bands: UNI (4.9-6.0 GHz), FCC (5.1-5.8 GHz), IC (5.4-5.8 GHz), ETSI (5.4-5.8 GHz)
•Subscriber Units Supported: 128 (2 x 64)
•Range: Up to 40 km (25 miles)
•Radio Access Scheme: OFDM, Auto MIMO 2x2 or Diversity per SU
•Max Tx Power: 25dBm per port (subject to the country regulation)
•Antenna Gain: 20 dBi
•PoE to ODU Interface: Outdoor CAT-5e; Maximum cable length: 100m for 10/100BaseT and 75m for 1000BaseT
•Data Interfaces: 1000BaseT (over PoE) or SFP
•QoS: Packet classification to 4 priority queues according to 802.1P or Diffserv
•VLAN Support: 802.1Q, QinQ, 4094 VLANs
•Operating Environment: Temperature -35°C to 60°C / -31°F to 140°F; Humidity 100% condensing

•1 x RADWIN JET DUO Base Station
