•Long-Range PoE+: With Extend Mode, PoE transmission distance reaches up to 250 m, perfect for surveillance camera deployment in large areas
•PoE Auto Recovery: It guarantees stable operation of PoE devices by automatically rebooting the dropped or unresponsive PD devices
•Metal Casing: Durable metal casing and desktop/wall-mounting design are well-suited for different environments
•Silent Operation: Industry-leading fanless design ensures silent operation, ideal for any home or business
•Plug and Play: No configuration and installation required
•Power Supply: The product only supports PoE power supply, not AC or DC power supply

•Interface: 1 × 10/100/1000 Mbps RJ45 PoE In Ports (compliance with 802.3af/at/bt Type3/bt Type4), 4 × 10/100/1000 Mbps RJ45 PoE Out Ports (compliance with 802.3af/at), AUTO Negotiation, AUTO MDI/MDIX
•Network Media: 10BASE-T = UTP category 3, 4, 5 cable (maximum 100m), EIA/TIA-568 100Ω STP (maximum 100m); 100BASE-TX = UTP category 5, 5e cable (maximum 100m), EIA/TIA-568 100Ω STP (maximum 100m); 1000BASE-T = UTP category 5, 5e, 6 or above cable (maximum 100m), EIA/TIA-568 100Ω STP (maximum 100m)
•Power Supply: Only Powered by PoE Device
•Fan Quantity: Fanless
•Max Power Consumption: 2.68 W (90W PoE In, with no PD connected); 68.59 W (90W PoE In, with 66 W PD connected)
•Max Heat Dissipation: 9.112 BTU/h (90W PoE In, with no PD connected); 233.206 BTU/h (90W PoE In, with 66 W PD connected)
•Switching Capacity: 10 Gbps
•Packet Forwarding Rate: 7.44 Mpps
•MAC Address Table: 2K
•Certification: CE, FCC, RoHS
•Operating Environment: Temperature -30°C to 70°C (-22°F to 158°F), Humidity 10%~90% non-condensing

•1 x TL-SG1005P-PD
•Installation Guide
