•Equipped with four 802.3af/at PoE+ ports with up to 30W for each port, data, and power can be transferred on one single cable
•Supports PoE power up to 120 W for all PoE ports*
•Provides network monitoring, traffic prioritization, VLAN features, and PoE Auto Recovery
•Simple network set-up on top of plug-and-play connectivity
•Web-based user interface and Easy Smart Configuration Utility simplify configuration
•Fanless design lowers energy consumption and eliminates operating noise
•QoS for a Lag-Free Experience - Ensures smooth traffic for latency sensitive applications, such as voice and video
•IGMP Snooping for Multicast Optimization - Ensures a better network experience, especially for IPTV, by optimizing multimedia traffic delivery
•VLAN for Security - Helps to create network with higher security and better overall performance by dividing network into smaller groups
•Automatically detects and reboots the PD devices when they fall offline or go unresponsive, guaranteeing the stable operation of PoE-connected devices
•Compliance with the 802.3af/at PoE+ standard supports up to 30 W on each PoE port, and it is fully compatible with more 802.3at PD devices
•Automatically detects the required PoE power for your device and protects your non-PoE equipment from being damaged

•Interface: 5 x 10/100/1000Mbps RJ45 Ports, AUTO Negotiation/AUTO MDI/MDIX
•Standards and Protocols: IEEE 802.3i, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3x, IEEE 802.1q, IEEE 802.1p, IEEE 802.3at
•Network Media: 10BASE-T = UTP category 3, 4, 5 cable (maximum 100m), EIA/TIA-568 100Ω STP (maximum 100m); 100BASE-TX = UTP category 5, 5e cable (maximum 100m), EIA/TIA-568 100Ω STP (maximum 100m); 1000BASE-T = UTP category 5, 5e, 6 or above cable (maximum 100m), EIA/TIA-568 100Ω STP (maximum 100m)
•Power Supply: External Power Adapter (Output: 53.5 VDC / 2.43 A)
•PoE Ports (RJ45): Ports 1-4, Standard: 802.3af/at compliant (Power Supply - 120W)
•Max Power Consumption: 4.34 W (220 V/50 Hz with no PD connected); 137.01 W (110 V/50 Hz with 120 W PD connected)
•Max Heat Dissipation: 14.8 BTU/h (with no PD connected); 467.17 BTU/h (with 120 W PD connected)
•Switching Capacity: 10 Gbps
•Packet Forwarding Rate: 7.44 Mpps
•MAC Address Table: 2K
•Certification: FCC, CE, RoHS
•Operating Environment: Temperature 0°C to 40°C (32 °F to 104 °F), Humidity 10%~90% non-condensing

•1 x TL-SG105MPE
•1 x Power Adapter
•Rubber Feet
•Installation Guide
