•120 W PoE Budget: 8× 802.3at/af-compliant PoE+ ports with a total power supply of 120 W
•Full Gigabit Ports: 8× gigabit PoE+ ports and 8× gigabit non-PoE ports provide high-speed connections
•Integrated into Omada SDN: Zero-Touch Provisioning, Centralized Cloud Management, and Intelligent Monitoring
•Centralized Management: Cloud access and Omada app for ultra convenience and easy management
•Robust Security Strategies: IP-MAC-Port Binding, ACL, Port Security, DoS Defend, Storm control, DHCP Snooping, 802.1X, Radius Authentication, and more
•Optimize Voice and Video Applications: L2/L3/L4 QoS and IGMP snooping
•Access Control List - obtain data in accordance with user-defined network rules and helps you create the network regulations you need
•Designate the priority of traffic based on QoS, ensuring latency-sensitive applications, like voice and video, remain clear and lag-free
•VLAN allows for logical grouping management of devices in different physical LANs, improving information security and reducing data congestion
•Designed for either wall mounting or desktop use

•Interface: 16 × 10/100/1000 Mbps RJ45 Ports (Ports 1–8 Support 802.3at/af PoE+), Auto-Negotiation/Auto MDI/MDIX
•Network Media: 10BASE-T = UTP category 3, 4, 5 cable (maximum 100m), 100BASE-TX/1000Base-T = UTP category 5, 5e or above cable (maximum 100m)
•Standards and Protocols: IEEE 802.3i, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3af, IEEE 802.3at, IEEE 802.3x, IEEE 802.1d, IEEE 802.1s, IEEE 802.1w, IEEE 802.1q, IEEE 802.1p, IEEE 802.1x
•Power Supply: External Power Adapter (Output: 53.5 VDC/ 2.43 A)
•PoE Ports (RJ45): Ports 1-8, Standard: 802.3af/at compliant (Power Supply - 120W)
•Max. Power Consumption: 146.5 W (110 V/60 Hz) (with 120 W PD connected)
•Max. Heat Dissipation: 499.98 BTU/hr (110 V/60 Hz) (with 120 W PD connected)
•Bandwidth/Backplane: 16 Gbps
•MAC Address Table: 8k
•Packet Buffer Memory: 4.1 Mbit
•Certification: CE, FCC, RoHS
•Operating Environment: Temperature 0°C to 40°C (32 °F to 104 °F), Humidity 10%~90% non-condensing

•1 x TL-SG2016P
•1 x Power Adapter
•Rubber Feet
•Installation Guide
