•The easy-to-read display provides status information: IP address, signal strength, and current throughput
•Powered by 24V passive PoE - a single cable to carry both power and data
•Up to 128 Nano G devices can be connected to a single GPON port
•Supporting GPON links of up to 20 km, the Nano G integrates with the UFiber OLT (UF-OLT) and third-party OLT devices

•Networking Interface Speeds: (1) GPON WAN, ITU G.984; 2.488 Gbps Downstream; 1.244 Gbps Upstream; (1) GbE LAN, 10/100/1000 Mbps
•Management Interface: In-Band Ethernet/PON
•Normal Optical Power Range: TX (Class B+): 1.5 dBm to 5 dBm, RX: -8 dBm to -28 dBm
•Power Method: Passive PoE (Pins +4, 5; -7, 8), Dying Gasp Support
•Power Supply: PoE Adapter: 24V, 0.3A (Included)
•Max. Power Consumption: 7W
•Supported Voltage Range: 20V to 28V
•Processor Specs: MIPS-32, 240 MHz
•Memory Information: 128 MB DDR3
•Buttons: (1) Display Information, (1) Reset
•Operating Temperature: -10°C to 45°C (14°F to 113°F)
•Certifications: CE, FCC, IC

•1 x UFiber Nano G GPON Optical Network Unit
•1 x Wall Mount Bracket
•4 x Screw
•4 x Screw Anchor
•1 x Gigabit PoE (24V, 0.3A) with Mount Bracket
•1 x Power Cord
•Quick Start Guide
