•1 x XG-PON port
•1 x 2.5GbE RJ45 LAN port and 24V PoE in
•Managed with UISP Application Version 1.5.7 and later
•This device is only compatible with the UISP Fiber XGS OLT. It cannot be used with third-party OLTs.

•Networking Interface: 1 x SC/APC, ITU-G.987 XGPON WAN port, 1 x 100/1,000/2,500 MbE RJ45 LAN ports
•Management Interface: Ethernet in-band, PON
•PoE interface: 1 x PoE in, 24V DC passive PoE
•Memory: 256 MB DDR
•Onboard Flash Storage: 32 MB NOR
•Max. Power Consumption: 6W
•Power Supply: 5V DC, 3A power adapter; Passive PoE 2-pair (4, 5+; 7, 8-)
•Total Non-blocking Line Rate: Downstream - 9.95 Gbit/s; Upstream - 2.44 Gbit/s
•Normal TX Range of Optical Module: 2dBm to 7dBm
•Normal RX range of optical module: -9dBm to -27dBm
•Operating Environment: Temperature -15°C to 45°C (5°F to 113°F); Humidity 10 to 95% non-condensing
•Certifications: CE, FCC, IC

•1 x UISP Fiber XG-PON 2.5Gbps CPE
•1 x Power supply
•Mounting hardware
