• 8 x 2.5 GbE PoE++ output ports
• 1 x 10 GbE PoE+++ input port for power / SFP+ port combo
• 196W PoE availability with optional AC power adapter (sold separately)

• Management Interface: Ethernet In-Band
• Networking Interface: 8 x 2.5/1 GbE RJ45 ports; 1 x 10G SFP+ or 10/5/2.5/1 GbE RJ45 combination port (While only one is active, RJ45 can receive power and SFP+ can be utilized for data)
• PoE Interface: 8 x 60W PoE++ (Pair A 1, 2+; 3, 6-) (Pair B 4, 5+; 7, 8-)
• Total Non-Blocking Throughput: 30 Gbps
• Switching Capacity: 60 Gbps
• Forwarding Rate: 44.64 Mpps
• Power Method: 1 x AC power adapter, 54V DC, 3.9A (Not included); 1 x PoE+++ (PairA 1, 2+; 3, 6-)(PairB 4, 5+; 7, 8-)
• Supported Voltage Range: AC/DC input - 54V DC (DC jack); PoE input - 50—57V DC
• Max. Power Consumption: PoE input: 14W (Excluding PoE output), AC input: 17W (Excluding PoE output
• Total Available PoE: PoE+++ input - 76W, PoE++ input - 46W, PoE+ input - 16W, 210W AC adapter input - 196W (power values do not account for losses caused by cable length)
• Operating Environment: Temperature -20°C to 45°C (-4°F to 113°F); Humidity 10 to 90% noncondensing
• Certifications: CE, FCC, IC

• 1 x Flex 2.5G PoE 8-port switch
• Mounting hardware

8.4-in x 3.9-in x 1.3-in

1.25 lbs
