• Etherlighting™ ports that illuminate to indicate port location, speed/link, and native VLAN/network (Pair with UniFi Etherlighting Patch Cables for optimal brightness)
• 22 x 2.5 GbE, 2 x 10 GbE PoE++ ports
• 4 x 10G SFP+ ports
• DC power backup ready (Requires UniFi RPS)
• 600W total PoE availability

• Management Interface: Ethernet In-Band
• Networking Interface: 2 x 10/5/2.5/1 GbE, 100 MbE RJ45 ports; 22 x 2.5/1 GbE, 100/10 MbE RJ45 ports; 4 x 10/1G SFP+ ports
• PoE Interface: 24 x 60W PoE++ (Pair A 1, 2+; 3, 6-) (Pair B 4, 5+; 7, 8-)
• Total Non-Blocking Throughput: 115 Gbps
• Switching Capacity: 230 Gbps
• Forwarding Rate: 171.12 Mpps
• Power Method: 1 x Universal input, 100—240V AC, 50/60 Hz; 1 x USP-RPS DC input
• Supported Voltage Range: 100—240V AC
• Max. Power Consumption: 56W (Excluding PoE output)
• Total Available PoE: 600W
• Operating Environment: Temperature -5°C to 40°C (23°F to 104°F); Humidity 10 to 90% noncondensing
• Certifications: CE, FCC, IC

• 1 x Pro HD 24 PoE
• 1 x Power Cable
• Mounting hardware

14.1 lbs

17.4-in x 15.7-in x 1.7-in
