• 90° sector coverage
• 5 GHz 800+ Mbps weather resilient backup radio
• Integrated GPS & Bluetooth
• Grounding stud
• Supported client count of 31
• GPS sync
• Hinge arm mounting
• Drain hole

• Processor: Quad-core ARM® Cortex®-A53 at 1.4 GHz
• Memory: DDR3L 512 MB
• Networking Interface: 1 x 2.5 GbE RJ45 port; 1 x 10G SFP+ port
• Max. Power Consumption: 24W
• Power Method: Passive PoE 4-pairs (1, 2+; 3, 6-) (4, 5+; 7, 8-); Passive PoE 2-pairs (4, 5+; 7, 8-), for 44–54V DC only
• Power Supply: 48V DC, 0.65A 2.5 GbE PoE adapter (Included)
• Total Throughput: 5.4 Gbps
• Max. Range: Connecting to a Wave Pro - up to 6 km, Connecting to a Wave Long-Range - up to 6 km, Connecting to a Wave Nano - up to 4 km, Connecting to a Wave Pico - up to 0.9 km
• Channel Bandwidth: 2160, 1080, 540 MHz
• Antenna Gain: 20 dBi
• Beamwidth: Azimuth 3 dB 90°, Elevation 3 dB 7°
• Wind Loading: 109.8 N at 200 km/h (25 lbf at 125 mph)

• 1 x Wave AP Gen2
• 1 x Power cable
• 1 x Mounting template
• 1 x Pole Mount
• Mounting hardware

3.3 lbs

6.2-in x 11.3-in x 3.9-in
