•Rugged design that is engineered to perform in the most critical seismic environments
•Includes generous stud locations for grounding and bonding applications
•Ganging holes allow for joining multiple cabinets
•C-channel struts provide cabinet strength, ease and flexibility to adjust mounting rails
•Flush-mount doors come with 3-point latching and stiffeners to reduce flexing and bowing while increasing cabinet security
•Cabinet frame constructed in 14-gauge steel cabinet with 12-gauge steel re-enforced corner brackets
•Cabinet doors and side panels constructed in 16-gauge steel
•Includes two (2) pairs of EIA compliant square hole mounting rails with rack unit markings
•Mounting rails are constructed in 12-gauge steel, and are Zinc-plated to provide superior surface areas for equipment grounding
•Dynamic (seismic) load rated up to 1,000 lb. (454 kg) of equipment installed and 100 lb. (45 kg) of cable weight on the top. Requires a seismic bolt down kit such as the C4K-Z4 (sold separately). Independently tested and certified to exceed established Seismic Zone 4 NEBS™ Telcordia® GR-63-CORE testing standards.
•UL Listed 2416 load rated for up to 3,000 lbs (1,360 kg). Static Load tested to 12,000 lbs (5,443 kg).
•Grounding studs bonded to frame, side panels and doors. Front and rear studs on cabinet frame conform to PET.

•RoHS Compliant: Yes
•REACH Compliant: Yes
•Material: Mild Steel
•cULus, Telcordia Zone 4, TAA-Compliant: Yes
•Rack Units: 44
•Rack Type: Open Rack
•Material Finish: Black
•UPC: 623980412238
•Shipping Dimensions: 46" x 34" x 84", 473 lbs

•Steel frame which includes nylon leveling feet, recessed casters and grounding studs
•2x Infinitely adjustable 19” EIA compliant square hole punched rails with rack unit markings
•2x Perforated front door (63% open area vented) with locking swing-handle
•2x Removable solid side panels
•Removable solid top panel
