•Thermostat control accessible from inside enclosure
•Hot gas bypass valve prevents evaporator freeze up while minimizing heavy inrush currents on large BTU/H units
•Built-in condensate evaporator
•Continuous air circulation from high capacity fans
•EMI/RFI suppression meets CE
•Self-diagnostics on startup
•Fault indication via LED light
•Provision for door contact allowing power down when enclosure door is opened
•Gasket, mounting kit and template for enclosure cutout and drilling are included
•Condensate drain hose and clamp provided
•Maintains enclosure's NEMA 12 rating
•Galvanized steel with RAL7035 light grey powdercoat finish for long-term durability

•Rated Voltage: 115 V 60Hz
•Range of Operation: 103-127 V
•Power Consumption: 845 W
•Running Amps: 7 A
•Starting Current: 15 A
•Line Cord: Terminal Block
•Cooling Capacity: 4100 BTU/h (1200 Watts)
•Type of Refrigerant: R134a
•Refrigerant Charge: 400 g
•Adjustable Control Range: +25°C to +45°C (77°F to 113°F) [Factory setting +95°F/+35°C]
•Min./Max. Ambient Air Temperature: 15°C (59°F) / 55°C (131°F)
•Air Capacity (unrestricted): Internal Circulation 177 CFM

•1 x Cooling Unit
•1 x Mounting Cutout
•1 x Gasket Kit
•1 x Mounting Kit
•Manual
•Technical Data Sheet
