•Optional locking doors are constructed in 16-gauge steel, the doors install in minutes and are available in vented, tinted window and solid
•The main body is constructed in 16-gauge welded steel and includes four (4) vents for optional fans on the sides of the cabinet
•Main body can be installed to swing from left-to-right or right-to-left
•Heavy duty rear bracket is constructed in 14-gauge welded steel and features a spring-hinge pin for easy installation and removal
•10-32 tapped rails are easy to remove on-site and replace with square hole rails (sold separately) if needed
•2.50"and 2.00"conduit knockouts are located on the side
•3.00", 2.00", 1.38"and 1.12"conduit knockouts are located on the top and bottom
•Fan knockouts/cable access located on the top and bottom
•Numerous cable management mounting points included
•Heavy duty keyhole for wall mounting
•Large openings in rear for cable access
•Dedicated bonding and grounding points that also provide drill-less mounting of electrical utility boxes.
•UL Listed 2416 load rated for up to 350 lbs (158 kg). Static Load tested to 1,400 lbs (635 kg).
