•Optional locking doors are constructed in 16-gauge steel, The doors install in minutes and are available in vented, tinted window and solid
•The main body is constructed in 16-gauge welded steel and includes four (4) vents for optional fans on the sides of the cabinet
•Main body can be installed to swing from left-to-right or right-to-left
•Heavy duty rear bracket is constructed in 14-gauge welded steel and features a spring-hinge pin for easy installation and removal
•2.50"and 2.00"conduit knockouts are located on the side, 3.00", 2.00", 1.38"and 1.12"conduit knockouts are located on the top and bottom
•Fan knockouts/cable access located on the top and bottom
•Numerous cable management mounting points included
•Heavy duty keyhole for wall mounting and large openings in rear for cable access
•10-32 tapped rails are easy to remove on-site and replace with square hole rails (sold separately) if needed
•Dedicated bonding and grounding points that also provide drill-less mounting of electrical utility boxes.
•UL Listed 2416 load rated for up to 350 lbs (158 kg). Static Load tested to 1,400 lbs (635 kg
•30-inch wide mounting rails include cutouts for optional 1U 19" accessories, such as cable management or power bars
