•The door is removable and swings more than 120 degrees
•The middle section swings to 130 degrees to access the rear pan, allowing for easy maintenance
•Both door and middle section include draw-latching locks, keyed alike
•The heavy-duty rear pan is constructed in 14-gauge welded steel and features a hinge pin for easy installation
•Bonding studs are provided on the door, body and back pan
•Dedicated bonding and grounding points that also provide drill-less mounting of electrical utility boxes
•Type 12 rated with a load rating of 350 lbs (158 kg)
•Rack rails are drilled and tapped 10-32 to EIA 19" standards and are finished in a smooth powder coat
•Manufactured in North America within an ISO 9001:2015 certified facility

•Body Material: 14-gauge welded steel
•Window Door Material: UV-resistant polycarbonate material
•Load Rating: 350 lbs (158 kg)
•Seismic Rating: 200 lbs (90.72 kg)
•Finish: RAL9005 black powder coat.
•Rail Type: Tapped 10-32
•REACH Compliant: Yes
•RoHS Compliant: Yes
•TAA-Compliant: Yes

•1 x 24W 12U NWC - Rear Assembly
•1 x 24W 12U NWC - Centre
•1 x 24W 12U NWC - Window Door
•2 x H1 12U - Panel Rail LH
•2 x H1 12U - Panel Rail RH
•4 x T12 6" Exhaust Filter
