•Holds up to 1,200 kg (2,645 lb)
•Can be installed on an aluminum, steel, or wooden door frame
•ANSI-compliant design

•Compatibility: UA-G2-SK-Pro, UA-G2-SK, EAH-8, UA-Hub
•Voltage: 12 V DC
•Current Power: 400mA ±10%
•Wiring Connection: Connect the two screw terminal separately to powered lock relay on UA-Hub: NO, COM
•Lock Type: Fail secure lock; Single door
•Lock Holding Force 1,200 kg (2,645 lb)
•Suitability: Wooden, steel, aluminum door
•Screw Terminal: + and -
•Lock Body Material: Zinc alloy
•Front Plate/Latches Material: Stainless steel
•Operating Environment: Temperature -10°C to 45°C (14°F to 113°F); Humidity 5 to 90% noncondensing
•Certifications: FCC, IC, CE

•1 x Lock Body
•1 x Long front plate
•2 x Short plates
•2 x M4 screws
•4 x M5 screws
