• 96 SuperLink clients with up to 2 km link range
• 7 UP-Sense BLE devices
• Status LED
• Optional USB=C power input
• Wall and DIN mounting options

• Networking Interface: 1 x 10/100 MbE RJ45 port
• Management Interface: Bluetooth® 5.2; SuperLink (Proprietary)
• Power Method: PoE; USB Type-C, 5V, 1A (Optional)
• Max. Power Consumption: 3.4W
• ESD/EMP Protection: Air ± 8kV; Contact ± 4kV
• Antenna gain: Bluetooth 3 dBi; SuperLink 1 dBi
• Max. TX Power: Bluetooth 10 dBm; SuperLink 27 dBm
• Max. Client Count: Bluetooth - 7; SuperLink - 96
• Ambient Operating Temperature: 0 to 40° C (32 to 104° F)
• Ambient Operating Humidity: 10 to 90% noncondensing
• Certifications: FCC, IC, CE
• NDAA Compliant: Yes

• 1 x SuperLink
• 1 x Mounting Template
• Mounting Hardware

0.39 lbs

6.3-in x 3.2-in x 1-in
