• PVC jacket
• Dry Gel Tape construction that swells and blocks water migration
• Shielded

• Total Number of Conductors: 8 (4-pairs)
• AWG: 24 (0.51 mm)
• Conductor Stranding: Solid
• Conductor Material: Bare copper
• Insulation Material: HDPE (1.02 mm)
• Max Recommended Pulling Tension: 35 lb (16 kg)
• Min Bend Radius (Install): 1.0 in (2.5 cm)
• Drain Wire: 26 AWG solid TC
• Impedance 1 MHz to 100 MHz: 100 Q ± 15 Q
• Nominal Mutual Capacitance @ 1 KHz: 15 pF/ft
• Operating Temperature Range: -40°C to 75°C
• Certifications: ETL CMG

• 1 x CAT5e Outdoor Shielded Dry Gel Tape 1000' Reel in Box

Datasheet
